Rapid-Deploy Prefabricated Cleanroom Unit with Pre-Wired Electrical System for Fast Project Expansion
| Brand Name: | SHP |
| Model Number: | Customized |
| MOQ: | 50 square meters |
| Price: | $500.00/square meters 50-499 square meters |
| Payment Terms: | L/C,T/T |
| Supply Ability: | ≥1 set |
Detail Information
Place of Origin:
China
Certification:
CE、ISO
Condition:
New
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Cosmetics, Electronics, Laboratories, Clean Room, Dust-free Workshop, Hospitals
Machinery Test Report:
Provided
Warranty Of Core Components:
1 Year
Cleanliness:
Class 100 To Class 100,000
HEPA Filter:
99.995%@0.3um Or As Required
Key Words:
Turnkey Solution Clean Room
Application:
Electronics, Food, Hospital
Certificate:
CE ISO
Item Name:
GMP Clean Room
Material:
Rock Wool Sandwich Panel Or Hollow Glass Magnesium Sandwich Panel
Work Scope:
Construction, HVAC, Electric, Process Piping
Packaging Details:
Wooden Case, Galvanized Steel Pallet, Plastic Film
Supply Ability:
≥1 set
Highlight:
prefabricated cleanroom unit with electrical system
,rapid-deploy cleanroom for project expansion
,pre-wired cleanroom unit fast installation
Product Description
Product Overview ——Rapid-Deploy Prefabricated Cleanroom Unit with Pre-Wired Electrical System for Fast Project Expansion
From nanometer-level particle control in chip lithography bays to microbial management in aseptic pharmaceutical filling lines, and the ultra-clean drying environment for lithium battery separator coating — cleanrooms deliver purpose-built controlled spaces for every precision process, utilizing staged filtration, positive/negative pressure cascades, and intelligent environmental monitoring.
Cleanroom Description
| Application | Pharmaceutical | Lab | Electronics |
| Cleanliness | China class 100 to 100000 | ISO 5 to 8 | EU B to D |
| Scope |
Structure part; Partition and ceiling panel; door and window,epoxy. |
HVAC part; AHU and chiller; Ducting and piping. |
Electrical part; Lamp,switch and socket; Distribution cabinet. |
| Service | Design and production | Construction and test | Validation and training |
| Wall/ceiling panel | Machine-made or Hand-made sandwich board |
| Clean room equipment | Air shower,FFU,Pass box,Laminar flow cabinet,hepa box |
| Cleanliness | Class 100-100000 |
| Purification system | HVAC, or AC conditioner+FFU |
| Floor | PVC anti-static floor or epoxy-based coating |
| Other addessores | stalinite window,LED panel light,Door,Hand wash sink,storage/shoe cabinet etc |
| Service | Design,manufacturing,construction |
Cleanroom Core Functions
1. Air Cleanliness Control
Multi-stage HEPA/ULPA filtration strips airborne particles down to ISO Class 1 levels — fewer than 10 particles per cubic meter at 0.1μm — delivering the ultra-clean air that precision manufacturing depends on.
2. Airflow Pattern & Distribution
Laminar, turbulent, or mixed-flow air distribution is engineered to sweep contaminants away from the work zone instantly, eliminating dead spots and maintaining a constant self-cleaning barrier around critical processes.
3. Temperature & Humidity Precision Control
Advanced HVAC regulation holds temperature to ±0.5°C and humidity to ±3% RH, creating a thermally stable envelope that protects sensitive processes like photolithography and aseptic filling from environmental drift.
4. Pressure Cascade & Contamination Isolation
Staged positive pressure cascades (5–15 Pa) between zones of differing cleanliness form an invisible shield — clean air always flows outward, preventing unfiltered air from ever entering critical areas.
5. Envelope Structure & Sealing
Seamless clean wall panels, flush ceilings, and airtight doors form a fully sealed enclosure with no dust traps — every joint is sealed tight, every corner rounded smooth.
6. Electrostatic Discharge (ESD) Control
Conductive flooring and integrated grounding networks safely bleed static charges to earth, keeping surface resistance in the 10⁴–10⁹ Ω sweet spot and shielding sensitive electronics from damaging discharges.
7. Personnel & Material Purification
Air showers, gowning rooms, and pass boxes create a staged entry protocol — high-velocity clean air scrubs personnel, while UV pass-throughs sanitize incoming materials before they reach the clean zone.
8. Intelligent Environmental Monitoring
Real-time sensors — particle counters, pressure transducers, temperature/humidity probes — feed live data to a central BMS/EMS that logs every reading, flags deviations instantly, and maintains a full audit trail for GMP compliance.
9. Energy Efficiency & Operational Optimization
Variable-speed fans, heat recovery wheels, and setback modes slash energy consumption during low-load periods without ever compromising cleanliness, delivering lower operating costs and a smaller carbon footprint.
10. Validation & Compliance Management
Full IQ/OQ/PQ protocols — filter integrity tests, airflow visualization, recovery time studies, and uniformity mapping — confirm that every cleanroom meets ISO 14644 and GMP standards from day one through its entire operational life.
Products Description
Pharma,Biotech&Labs
With today's new regulations and growing concernforpublicsecurity,pharmaceutical,biotech and medical device industries need to maintain and upgrad their facilities in order to meet new requirements and regulations.SHP's in-house experts have the necessary experience in designing building and installin cleanrooms and enclosures to be compliant with new standards.And our knowledge and experience cove a wide range such as infusion production, tablet making and vaccine project,etc.
Electronic,Semiconductors&High-tech Industry
SHP designs,manufactures and installs cleanrooms for the semiconductor and high-technology sectors,from optics,photonics to the assembly of electronic components.In these induatries,products are often very sensitive to airborne particulates and must be manufactured in a controlled environment.Inaddition,these industries often require the use of ultra-precise and costly equipment that must be housed and operated in a location where temperature and humidity are maintained at a specific level.
Hospital
SHP designs and installs cleanrooms that can work well for hospital and pharmaceutical applications and are of high quality to meet stringent cleanroom standards.High levels of environmental control are required to protect patients' health.SHP constructs cleanrooms that can incorporate existing structures or stand freely and offers a high level of environmental control including static,pressure,contamination,and humidity control can be designed to comply with even the most stringent medical standards.
Food Processing&Packaging
Food Processing is an industry where product safety,quality,and integrity are paramount.Assuch,cleanrooms are vital in the food manufacturing industry to ensure food product quality and to adhere to GMP(ISO) standards and requirements,In food manufacturing,cleanrooms must generally meet ISO Class 6 standards.We offer a variety of options to meet your application's specific needs,from highly controlled HardWall cleanrooms that can be built to comply with the most stringent classification to SoftWallcleanrooms with a high degree of flexibility thatwork well for food storage and similar uses.
Manufacturing Industry
Authoritative documents such as ISO 14644 provide no specific instructions regarding activities carried out in other manufacturing industry such as medical device enbvironment.Broadly,medical device manufacturing is conducted in an ISO Class 5 cleanroom(Feb.Class 3),while medical device packaging is conducted in an ISO Class 7-8 cleanroom.Guaranteed completion and final compliance testing are among the reasons SHP is a trusted ally of enterprise in this area as well.
