Standard Modular Cleanroom Building Projects All In One One Stop Fabrication
| Brand Name: | SHP |
| Model Number: | Customized |
| MOQ: | 50 square meters |
| Price: | $500.00/square meters 50-499 square meters |
| Payment Terms: | L/C,T/T |
| Supply Ability: | ≥1 set |
modular cleanroom building solutions
,standard cleanroom fabrication services
,all-in-one cleanroom construction projects
Standard Modular Cleanroom Building Projects All In One One Stop Fabrication
Product Overview
Cleanroom Description
| Application | Pharmaceutical | Lab | Electronics |
| Cleanliness | Class 100–100000 or applicable ISO/GMP classification | ISO 5–8 or project-specific classification | ISO 5–8 or project-specific classification |
| Scope |
Structure part; Partition and ceiling panel; door and window,epoxy. |
HVAC part; AHU and chiller; Ducting and piping. |
Electrical part; Lamp,switch and socket; Distribution cabinet. |
| Service | Design and production | Construction and test | Validation and training |
| Wall/ceiling panel | Machine-made or Hand-made sandwich board |
| Clean room equipment | Air shower,FFU,Pass box,Laminar flow cabinet,hepa box |
| Cleanliness | Class 100-100000 |
| Purification system | HVAC, or AC conditioner+FFU |
| Floor | PVC anti-static floor or epoxy-based coating |
| Other addessores | stalinite window,LED panel light,Door,Hand wash sink,storage/shoe cabinet etc |
| Service | Design,manufacturing,construction |
Cleanroom Core Functions
- Pollution Control
Eliminate airborne particles and microorganisms to stop cross-contamination and product defects.
- Constant Environment
Precisely regulate temp, humidity and differential pressure against material damage and static.
- Improve Production Yield
Ultra-clean space cuts wastage and maintains consistent quality across product batches.
- Safeguard Precision Equipment
Less dust deposition reduces machine wear, prolongs equipment life and lowers upkeep cost.
- Protect Workers’ Health
Positive pressure isolation keeps harmful contaminants away from operating staff.
- Meet International Norms
Compliant with ISO 14644 for electronics, medical, food and optical industrial inspections.
- Anti-static & Risk Avoidance
Humidity control discharges static, protects sensitive parts and avoids fire dangers.
Cleanroom Applications
Pharmaceutical & Biotechnology
Modular cleanroom systems can be configured for pharmaceutical and biotechnology applications requiring controlled airborne contamination, environmental conditions and pressure relationships.
Laboratory & R&D
Prefabricated cleanrooms can be adapted for laboratory, testing and research environments according to the required cleanliness classification and process conditions.
Electronics & Semiconductor
Cleanroom configurations can support electronics and precision manufacturing processes where airborne particle and environmental control are important.
Medical & Healthcare
Cleanroom systems can be configured for selected medical, healthcare and controlled production environments according to applicable project requirements.
Integrated Cleanroom System Components
Complete Cleanroom Material and Equipment Supply
In addition to cleanroom engineering services, SHP supplies the standard cleanroom panels, HVAC systems, HEPA filtration and cleanroom doors essential to turnkey cleanroom project delivery.
The following image shows the major systems and products commonly integrated into SHP cleanroom projects.
Relevant Cleanroom Project Experience
Pharmaceutical Cleanroom Delivery – Mauritius
Project Location: Mauritius
Sector: Pharmaceutical Manufacturing
Project Type: Turnkey Cleanroom Project
Cleanliness Level: ISO 7
Scope of Work: Design, HVAC, Installation and Validation
Final Status: Successfully Delivered
Cleanroom Testing & Validation
Cleanroom performance is verified against the project requirements using appropriate testing procedures. Subject to the cleanroom configuration and applicable standards, testing may cover airborne particle counting, airflow velocity, differential pressure, temperature, humidity, illumination, noise and filter integrity checks where applicable.
If required, SHP can assist with project qualification documentation such as DQ, IQ, OQ and PQ.
