Stainless Steel Single Person Air Shower Room The Best Choice for Food Beverage

Product Overview

Air Shower

An Air Shower is a dedicated purification device installed at the entrance of cleanrooms or controlled environments, also referred to as an air shower tunnel or air shower gate. Its core purpose is to remove particulate contaminants (e.g., dust particles, hair, dander, and surface debris) adhering to the surfaces of personnel, workpieces, or materials before they enter the clean area.

How the Air Shower Works

An air shower is typically installed between the gowning area and the controlled cleanroom area as part of the personnel purification route.

• 1. Personnel Entry
  Staff enter the air shower from the gowning or lower-cleanliness side.
• 2. Door Interlocking
  An interlocking system controls the entrance and exit doors to help keep both doors from being opened at the same time during normal operation.
• 3. Air Shower Cycle
  Filtered air is delivered through directional nozzles, removing loose particles from the exposed surfaces of cleanroom garments.
• 4. Air Recirculation and Filtration
  The air circulation system recovers air and guides it through the filtration system in line with the equipment configuration.
• 5. Cleanroom Entry
  Once the programmed shower cycle is completed, the exit door can be released so that personnel proceed into the controlled area.

The actual shower cycle, airflow configuration, filtration arrangement and control logic should be chosen according to the cleanroom design and project requirements.

Features at a Glance

• 360° Purge to Remove Surface Contaminants
• Form an Air Curtain Barrier to Block Unpurified Air Infiltration
• Ensure Compliant Operation of Cleanrooms and Reduce Contamination Risks
• Intelligent Control to Improve Purification Process Efficiency
• Adapt to Differentiated Scenario Purification Needs

Main Components & Construction

Technical Specifications

Main Specification for Air Shower

Air Shower Types & Configurations

Cleanroom Applications

Air shower rooms are usually integrated into the personnel purification route between the gowning areas and controlled cleanroom spaces.

Common applications include:

• Pharmaceutical production
• Healthcare and medical facilities
• Laboratory settings
• Semiconductor and electronics manufacturing
• Beverage and food processing
• Cosmetic manufacturing
• Precision engineering

The air shower configuration ought to be selected together with the cleanroom layout, personnel flow, cleanliness requirements and operating procedures, not as an isolated equipment component.

Engineering & Customization Process

• 1. Requirement Analysis
  Review the cleanroom classification, personnel flow, available installation space and operating requirements.
• 2. Configuration Design
  Choose the air shower type, dimensions, door arrangement, filtration and control configuration according to the project.
• 3. Manufacturing
  Manufacture and assemble the chamber, filtration system, fan section, doors and control components according to the approved configuration.
• 4. Factory Inspection
  Check the assembled unit, electrical system, door operation, interlock function and other applicable items before shipment.
• 5. Installation & Commissioning
  Support the site installation, connection and functional commissioning according to project requirements.
• 6. Documentation
  Supply applicable product drawings, operation instructions, maintenance information and testing records.

Testing & Validation

• Visual check
• Dimensional inspection
• Door function test
• Interlock function test
• Fan function test
• Light test
• Control panel check
• Verification of airflow
• HEPA filter integrity test where applicable

Company Profile

As a leading supplier of clean room system and clean room products,SHP is an organization that prides itself both on technical expertise as well as next level customer care.SHP offers Cleanroom Solutions to meet our clients' particular requirements specialized for pharmaceutical,biotechnology and microelectronic cleanrooms.We also provide a range of Clean Room products including wall panel,door&window and a series of clean room equipment.

As an ISO 9001:2015 certified organization,we are committed to continually improving our customer service programs while meeting or exceeding your product quality criteria.With our comprehensive customer solution offerings,excellence in products,and decades of technical expertise,we are confident that SHP can match the best to your application.

Customer Photos

Products Description

• Slide rail style door closer:A slide rail door closer for air showers is a high-durability, high-precision core functional component designed to safeguard cleanroom environments.
• LCD control screen:The LCD control panel is not only the "intelligent brain" of the air shower but also a critical component that enhances equipment reliability, operational efficiency, and management standards.
• Stainless steel nozzle:For cleanrooms with high standards, high-frequency usage, and stringent certification requirements (such as those in , biotechnology, microelectronics, precision instruments, etc.), stainless steel nozzles are an essential and wise choice. They offer exceptionally long service life, nearly zero maintenance costs, and irreplaceable reliability.
• High efficiency filter:The HEPA filter is the "lungs" of the air shower, directly determining the quality of the blown air. Its ultra-high filtration efficiency, stable performance, and compliance are non-negotiable advantages.

Related Products

Our Customers

Packing and Shipping

Why Choose SHP

FAQ

Q1: Where is your company?

A1:Our company is located in Suzhou City, close to Shanghai. It's a 1.5-hour drive from PVG Airport.

Q2: Are you a manufacturer or a trading company? What can I buy from you?
A2: We are manufacturers. We focus on cleanroom projects, air showers, FFUs, through boxes, dosing rooms, laminar flow hoods and benches, AHUs, and sealed doors and Windows.

Q3:When is your delivery time?
A3: If your cleanroom project includes AHU, the delivery time is 35 days. If you purchase goods without an AHU, the delivery time is 10 days.

Q4: How long is your warranty period? What kind of after-sales service can you offer?
A4: Our warranty period is two years after the completion of the project. During the warranty period, if there are any problems, we will replace it. If you can't handle it, we will send an engineer to solve it for free.

Q5:Can you conduct cleanroom validation?
A5: Yes, we can offer documentaries of DQ, IQ, OQ and PQ. Still fat & Sitting. Product operation manual, maintenance guide and a complete set of cleanroom drawings.

Q6:What are your advantages?
A6: We have a complete technical team consisting of 12 senior cleanroom and HVAC engineers to provide you with technical support. We have completed over 2,100 cleanroom projects in China and overseas. Such as Japan, Indonesia, Thailand, Bangladesh, India, North Macedonia, Saudi Arabia, Yemen, Russia, Moldova, Switzerland, Norway, the United Kingdom, Spain, France, Belgium, Kuwait, Tunisia, Mauritius, Sri Lanka, Mongolia, Philippines, Nepal, Sudan, Somaliland, Australia, New Zealand, Canada, Algeria, Egypt, Singapore, and the United States.
