Scalable Modular Cleanroom Partition System with Interlocking Panels for Versatile Technical Environments
| Brand Name: | SHP |
| Model Number: | Customized |
| MOQ: | 50 square meters |
| Price: | $500.00/square meters 50-499 square meters |
| Payment Terms: | L/C,T/T |
| Supply Ability: | ≥1 set |
Detail Information
Place of Origin:
China
Certification:
CE、ISO
Condition:
New
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Cosmetics, Electronics, Laboratories, Clean Room, Dust-free Workshop, Hospitals
Machinery Test Report:
Provided
Warranty Of Core Components:
1 Year
Cleanliness:
Class 100 To Class 100,000
HEPA Filter:
99.995%@0.3um Or As Required
Key Words:
Turnkey Solution Clean Room
Application:
Electronics, Food, Hospital
Certificate:
CE ISO
Item Name:
GMP Clean Room
Material:
Rock Wool Sandwich Panel Or Hollow Glass Magnesium Sandwich Panel
Work Scope:
Construction, HVAC, Electric, Process Piping
Packaging Details:
Wooden Case, Galvanized Steel Pallet, Plastic Film
Supply Ability:
≥1 set
Highlight:
modular cleanroom partition system
,cleanroom interlocking panels
,scalable cleanroom system
Product Description
Product Overview ——Scalable Modular Cleanroom Partition System with Interlocking Panels for Versatile Technical Environments
A cleanroom comprises five key subsystems: HVAC purification (temperature, humidity, and cleanliness control), air filtration (three-stage pre/medium/HEPA filtration), envelope structure (clean panels, ceilings, doors), flooring (anti-static epoxy or raised access floor), and intelligent monitoring (particle counters, pressure sensors) — all working in synergy to sustain long-term environmental stability.
Cleanroom Description
| Application | Pharmaceutical | Lab | Electronics |
| Cleanliness | China class 100 to 100000 | ISO 5 to 8 | EU B to D |
| Scope |
Structure part; Partition and ceiling panel; door and window,epoxy. |
HVAC part; AHU and chiller; Ducting and piping. |
Electrical part; Lamp,switch and socket; Distribution cabinet. |
| Service | Design and production | Construction and test | Validation and training |
| Wall/ceiling panel | Machine-made or Hand-made sandwich board |
| Clean room equipment | Air shower,FFU,Pass box,Laminar flow cabinet,hepa box |
| Cleanliness | Class 100-100000 |
| Purification system | HVAC, or AC conditioner+FFU |
| Floor | PVC anti-static floor or epoxy-based coating |
| Other addessores | stalinite window,LED panel light,Door,Hand wash sink,storage/shoe cabinet etc |
| Service | Design,manufacturing,construction |
Cleanroom Core Functions
1. Air Filtration Multi-stage filtration — pre-filter, medium filter, HEPA/ULPA terminal — strips airborne particles to levels compliant with the target ISO 14644-1 classification. This is the foundational function upon which all others depend.
2. Airflow Management Clean air is directed through the space via turbulent dilution or laminar displacement patterns, sweeping contaminants away from generation sources and preventing particle settlement on critical surfaces.
3. Temperature & Humidity Control The HVAC system holds temperature within ±0.5°C to ±2°C and relative humidity within ±3% to ±5% RH, delivering a stable thermal-humidity envelope for precision processes.
4. Pressure Cascade A 5–15 Pa positive pressure gradient is maintained between clean and less-clean zones. Physics handles the rest — air flows only outward, blocking external contamination at every boundary.
5. Physical Containment Clean wall panels, sealed ceilings, and airtight doors form a fully enclosed shell. All joints are sealed, all internal corners are radiused, eliminating every surface where dust could accumulate.
6. ESD Grounding Conductive flooring integrated with the grounding system maintains surface resistance within the 10⁴–10⁹ Ω range, continuously bleeding static charges from personnel, equipment, and materials.
7. Personnel & Material Decontamination Gowning rooms, air showers, buffer zones, and pass boxes create a staged entry protocol — physically stripping contamination from people and items before they reach the clean zone.
8. Real-Time Monitoring Online particle counters, pressure transducers, and temperature/humidity sensors stream live data to a central monitoring system, enabling instant deviation alerts and a fully traceable operational record.
Products Description
Pharma,Biotech&Labs
With today's new regulations and growing concernforpublicsecurity,pharmaceutical,biotech and medical device industries need to maintain and upgrad their facilities in order to meet new requirements and regulations.SHP's in-house experts have the necessary experience in designing building and installin cleanrooms and enclosures to be compliant with new standards.And our knowledge and experience cove a wide range such as infusion production, tablet making and vaccine project,etc.
Electronic,Semiconductors&High-tech Industry
SHP designs,manufactures and installs cleanrooms for the semiconductor and high-technology sectors,from optics,photonics to the assembly of electronic components.In these induatries,products are often very sensitive to airborne particulates and must be manufactured in a controlled environment.Inaddition,these industries often require the use of ultra-precise and costly equipment that must be housed and operated in a location where temperature and humidity are maintained at a specific level.
Hospital
SHP designs and installs cleanrooms that can work well for hospital and pharmaceutical applications and are of high quality to meet stringent cleanroom standards.High levels of environmental control are required to protect patients' health.SHP constructs cleanrooms that can incorporate existing structures or stand freely and offers a high level of environmental control including static,pressure,contamination,and humidity control can be designed to comply with even the most stringent medical standards.
Food Processing&Packaging
Food Processing is an industry where product safety,quality,and integrity are paramount.Assuch,cleanrooms are vital in the food manufacturing industry to ensure food product quality and to adhere to GMP(ISO) standards and requirements,In food manufacturing,cleanrooms must generally meet ISO Class 6 standards.We offer a variety of options to meet your application's specific needs,from highly controlled HardWall cleanrooms that can be built to comply with the most stringent classification to SoftWallcleanrooms with a high degree of flexibility thatwork well for food storage and similar uses.
Manufacturing Industry
Authoritative documents such as ISO 14644 provide no specific instructions regarding activities carried out in other manufacturing industry such as medical device enbvironment.Broadly,medical device manufacturing is conducted in an ISO Class 5 cleanroom(Feb.Class 3),while medical device packaging is conducted in an ISO Class 7-8 cleanroom.Guaranteed completion and final compliance testing are among the reasons SHP is a trusted ally of enterprise in this area as well.
